This weekend I came across Prez Jordan's post on Julia sets, I then followed the trail back to his original post on the Mandelbrot set. I've always loved fractals, since I read Gleick's Chaos back in school, and I used to spend hours generating Mandelbrot images on my Amiga when I should have been learning CS at University. I did at one point try to write my own Mandelbrot generator, but quickly got bogged down in trying to manage enough code to get a basic UI in Workbench and gave up and went to the pub.

Anyway, Prez's post stirred my memories and inspired me to once again try to put together my own Mandelbrot generator. Except this time, instead of having to manage OS libraries and indirect addressing in C just to open a window, I would take advantage of the HTML5 Canvas element:

The canvas element provides scripts with a resolution-dependent bitmap canvas, which can be used for rendering graphs, game graphics, or other visual images on the fly.

Basically, canvas creates an area on your web page on which you can then draw lines, curves, images, and text with Javascript. It allows you to do some pretty crazy things, a lot of the more spectacular early HTML5 examples used it.

Adding a canvas to the page is very simple:

<canvas id="mandelbrot" width="320" height="240">A mandelbrot fractal will appear here.</canvas>

The content of the element will only appear if the user agent does not support canvas, it's similar to a noscript block. If your browser does have support, then all the content the user sees will be drawn on with Javascript. You'll notice I specified the width and height, if I left that out it would default to 300 pixels wide by 150 pixels high, which has an interesting side effect I'll discuss below, otherwise, it's much the same as any other element. It doesn't have much in the way of default styling, and it's an inline, rather than block level, element, but you can target it with CSS rules:

canvas {
    -moz-box-shadow: rgb(0,0,0) 0px 2px 3px 3px;
    -webkit-box-shadow: rgb(0,0,0) 0px 2px 4px;
    box-shadow: rgb(0,0,0) 0px 2px 3px 3px;
}

So, we now have an empty rectangle with a nice drop shadow, how do we actually draw something? To draw on a canvas you need to get the context object, which in turn gives you access to all the drawing methods:

var canvas = document.getElementById('mandelbrot');
if (canvas.getContext){
    var ctx = canvas.getContext('2d');
    ctx.fillText('Hello World', 50, 50);
}

To draw a Mandelbrot we need to be able to plot single pixels across the whole element. There isn't a plot method, canvas isn't really intended for pixel by pixel manipulation, but we can pick a colour and plot a one pixel by one pixel rectangle:

var canvas = document.getElementById('mandelbrot');
if (canvas.getContext){
    var x=1, y=1;
    var ctx = canvas.getContext('2d');
    ctx.fillStyle = 'rgb(255,0,0)';
    ctx.fillRect(x,y,1,1);
}

So now you know enough about the canvas element to write a Mandelbrot generator, for the rest we can just steal code off the internet Here's what we're aiming for (warning - don't click on the link on a slow computer, it'll take several seconds to render):

Going back to Prez's post, his code is in Python, but it's fairly straightforward looking and easy enough to translate into Javascript. I took the Complex number library from "9.3.6. Example: Complex Numbers" of JavaScript: The Definitive Guide, 5th Edition and then used it to reimplement the Python function:

function mandel(c) {
    var cols = ["rgb(255,0,0)", "rgb(255,165,0)", "rgb(255,255,0)", "rgb(165,255,0)", "rgb(0,255,255)", "rgb(0,165,255)", "rgb(165,0,255)", "rgb(0,0,255)"];
    var z = new Complex(0,0);
    for (var i = 0; i <=20; i++) {
        z = Complex.add(Complex.multiply(z,z), c);
        if (z.magnitude() > 2) {return cols[i % cols.length]}
    }
    return "rgb(0,0,0)";
}

The function returns a different colour based on how many iterations it takes for z to exceed 2 in magnitude when combined with the input value c in the formula z * z + c (if it doesn't exceed 2, then it is in the Mandelbrot set, and so it's black). The input value is the pixel position on our canvas element except translated into a complex number - where the x axis is the real component and the y axis the imaginary one - ctx.fillStyle = mandel(c);. Check the Wikipedia page for full details of how the Mandelbrot set works, I worked out most of the details through trial and error once I had it functional.

I mentioned the default size for a canvas element above, this is 300px by 150px. As an experiment I removed the width and height attributes from the element itself and set the size of the canvas in CSS:

canvas {
    width: 45%;
    height: 45%;
}

You can view the results here (again, watch out if you have a slow computer). The browser renders the canvas, then scales the results to fit the CSS dimensions. So, if you want your canvas to take up a particular portion of the page (eg. half of it), you need to set the dimensions of the element with Javascript based on the pixel width of the page.

Moving on to Prez's second post, which inspired this whole adventure, where he looks at the Julia set. The Julia calculation is very similar to the Mandelbrot one, except instead of starting with z = 0 like the Mandelbrot it starts with z = t, where t is a complex number. The obvious place to get t is the existing plane of numbers on which we've drawn our Mandelbrot set. A canvas is an element like any other, so simply attach an onclick event to it and then work out the value of t from where the click event fired. Here's the Julia set for real 0.4249, i -0.2666:

You can take a look at the final Canvas Mandelbrot/Julia Generator here. In performance terms, doing a calculation to render each individual pixel is a pathologically bad case for canvas - it's not something you'd normally do, you would make use of the higher level drawing controls instead. As it stands it does make an interesting performance comparator between browsers. I tested it in Firefox 3.6 (about 2 seconds to generate each image on my machine), Google Chrome 5 beta (about 1 second for each image) and Opera 10.50 (about half a second for each image), it ought to work in Safari too but I didn't try it. I did a version which used Explorer Canvas to try and see how long IE took, but it kept hitting the script timeout before it was even one third of the way through.

• The Seven Deadly Sins Of JavaScript Implementation - Smashing Magazine - JavaScript development has changed a lot in recent years but the rules for solid, maintainable and secure JavaScript haven’t. Christian runs through the seven sins of JavaScript development that lead to unmaintainable code.Tags: BlogPost; Javascript; Tips;
• an HTML5 offline image editor and uploader application ✩ Mozilla Hacks – the Web developer blog - Uses drag and drop, cross domain XHR, canvas and offline to provide a desktop-like application in browser.Tags: BlogPost; HTML5; Firefox; Javascript;
• YUI Theater — Christian Heilmann: “YQL and YUI: Building Blocks for Quick Applications” (48 min.) [English and German versions available] » Yahoo! User Interface Blog (YUIBlog) - Rapid application development with YQL and YUI.Tags: Presentation; Javascript; BlogPost; SemanticWeb; Videos;
• Hg Init: a Mercurial tutorial by Joel Spolsky - An excellent introduction to using Mercurial for version control across a team of developers.Tags: Development; Tools; Tutorial;
• NVDA - Open source screen reading software for Windows.Tags: Accessibility; Tools; Python; Windows;
• Orca - GNOME Live! - The Gnome based open source screen reader software.Tags: Accessibility; Tools; Linux;

• What Web Designers need to know about EPUB | Nimbupani Designs - With the rise of eBook readers, take the opportunity to diversify while taking advantage of your existing markup skills.Tags: HTML; Books;
• Track down your stolen laptop – Prey - Use your webcam to take snapshots of that nasty person who stole your laptop.Tags: Security; Software; OpenSource;
• XUL accessibility guidelines - MDC - Take advantage of the accessibility features in Firefox 3.5+ and Thunderbird 3.0+ when writing extensions.Tags: Accessibility; FirefoxExtensions; Development; HowTo;
• Eric's Archived Thoughts: Fixed Monospace Sizing - A detailed examination of the non-intuitive way browsers size monospaced fonts.Tags: BlogPost; CSS; Typography;
• Dynamic Dummy Image Generator - DummyImage.com - Utility to create blank images at a specified size to help laying out page designs.Tags: Web; Design; Tools; Graphics; PHP;

• Extended Date Time Format (Library of Congress) - There is no standard date/time format that meets the needs of various well-known XML metadata schemas, this website describes the current effort to define an extended date/time definition.Tags: XML; Standards;
• http://carlos.bueno.org/2010/02/measuring-javascript-parse-and-load.html - There's a lot of coverage of how fast different browsers execute Javascript code, but less of how fast it is loaded and parsed prior to execution, this post attempts to redress the balance.Tags: BlogPost; Javascript; Performance;
• persistence.js: An Asynchronous Javascript ORM for HTML5/Gears « I am Zef - An ORM for the Web SQL Database standard, intended for use in offline applications on mobile browsers.Tags: BlogPost; HTML5; Javascript;
• The time element (and microformats) | HTML5 Doctor - The (current lack of) role of the time element within Microformats and, within the comments, a discussion of why the current generation of uF tools don't support HTML5.Tags: BlogPost; HTML5; Microformats;
• Keith Clark - IE CSS3 pseudo-class selectors - Allows Internet Explorer to identify CSS3 pseudo-class selectors and render any style rules defined with them.Tags: CSS; IE6; IE7; IE8;
• universal-ie6-css - Project Hosting on Google Code - Remove all the bother of making your flashy site work in IE6, instead just display the content in a standard, readable manner.Tags: IE6; CSS; Standards;

I've done a number of posts recently on new features coming in CSS level 3. These posts have mostly been based on features available in the version fours of Safari and Chrome and the Firefox 3.6 release so, while they may be useful if you're producing an iPhone app, they don't seem like they'll be much use on general purpose websites where IE users need to be considered. In this post I'm going to look at how these new CSS features can be made to work, or at least degrade gracefully, in older browsers, including Internet Explorer. I'm going to extend the example from my earlier post on scaling background images and gradients to see what's possible.

So my scaled background image looks OK in Firefox 3.6:

But it looks a bit crappy in Firefox 3.5, not to mention any other browser which doesn't support background-size:

There are going to be some cases where there's nothing you can do, for instance if you want some page elements to be in position over bits of the background, and will just need to take another approach (like putting the image in the page and using a negative z-index). However, in my case, I think that if users can't be treated to a nice full screen photo of palm trees then a tiling 'leafy' image would be an acceptable substitute without ruining the ambience. In order to provide one background image to browser which support sizing and another to those that don't I'm going to make use of another CSS3 feature, multiple background images. In CSS3 compatible browsers you can just provide multiple images in a comma separated list:

background-image: url('1-rhus-typhena-leaf-tile.jpg'), url('bg-image-1.jpg');

All the other background rules accept a similar comma separated list, including background-size. The nice thing about this is the stacking order of the images is defined in the spec:

The first image in the list is the layer closest to the user, the next one is painted behind the first, and so on. The background color, if present, is painted below all of the other layers.

So I put the tiling image 'closest to the user' then in my background-size set it to be zero size. Browsers which support background-size make that image disappear and show the scaled image behind it, those that don't show the tiling image:

background-size: 0% 0%, 100% 100%;
-moz-background-size: 0% 0%, 100% 100%;           /* Gecko 1.9.2 (Firefox 3.6) */
-o-background-size: 0% 0%, 100% 100%;             /* Opera 9.5 */
-webkit-background-size: 0% 0%, 100% 100%;        /* Safari 3.0 */
-khtml-background-size: 0% 0%, 100% 100%;         /* Konqueror 3.5.4 */

Note, the image doesn't actually disappear in WebKit, but if you set background-repeat: no-repeat it's very hard to spot. Opera 10.10 supports background-size (on Windows, anyway) but not multiple background images, which is unfortunate, but things work well on Opera 10.50. So now all we have to worry about is those browsers which don't support background-size or multiple background images. This is easy enough, as they should ignore all the rules they don't understand, so we just need to precede all of the above with a single background-image rule

background-image: url('1-rhus-typhena-leaf-tile.jpg');

Now each browser displays a background image according to their abilities, here's Firefox 3.5 after the fix:

With one further tweak, we can support IE too. The issue with IE is that it parses the multiple background images even though it doesn't understand them, treating them as a single, invalid background image. For this I resort to IE conditional comments:

<!--[if IE]>
<style type="text/css">
body {
    background-image: url('1-rhus-typhena-leaf-tile.jpg');
}
</style>
<![endif]-->

Something still needs to be done about the menu examples; to refresh your memory, the first menu example used a single 'button' background image:

This is amenable to the same multiple background hack. This time I used a one pixel wide slice of the button image and repeated it across the background:

background: url('bg-image-3.png') repeat-x;
background: url('bg-image-3.png') no-repeat, url('bg-image-2.png') no-repeat;   /* Image courtesy of http://blog.entropiads.com/2009/01/29/free-3-d-glossy-button-icons/ */
background-size: 0 0, 100% 100%;
-moz-background-size: 0 0, 100% 100%;           /* Gecko 1.9.2 (Firefox 3.6) */
-o-background-size: 0 0, 100% 100%;             /* Opera 9.5 */
-webkit-background-size: 0% 0%, 100% 100%;        /* Safari 3.0 */
-khtml-background-size: 0% 0%, 100% 100%;         /* Konqueror 3.5.4 */

Add some rounded corners and you end up with a reasonable approximation of the original buttons in Firefox 3.5:

The next set of buttons all used gradient backgrounds:

I'm just going to look at the first and the last one of these, as all the interesting bits will get covered in these two cases. One thing worth noting at this point - the syntax for specifying gradients has changed significantly in Firefox (and the standard) since the last time I discussed them. It's actually now a lot simpler. Old way:

background-image: -moz-linear-gradient(top, bottom, from(#090), to(#060), color-stop(25%, #cfc));

New way:

background-image: -moz-linear-gradient(top, #090, #cfc 25%, #060);

As you can see, the from, to and color-stop tokens have been removed and now, instead of stating the start and end colours and then any steps in between after that, the colours are now in the order they'll appear. The percentage value is now optional, if you don't specify it then the colour stops will be evenly distributed.

Because this example involves no transparency, supporting browsers which don't understand gradients is easy - just provide a background colour:

background-color: #080;
background-image: -moz-linear-gradient(top, #090, #cfc 25%, #060);
background-image: -webkit-gradient(linear, left top, left bottom, from(#090), to(#060), color-stop(25%, #cfc));

And (for a bit of variety), here's what it looks like in Opera 10.50 Alpha (on Linux):

You might settle for that in Internet Explorer, but you don't need to! IE has supported gradients since 5.5 thanks to the gradient filter. Here's a simple lighter to darker green gradient in IE8 CSS syntax:

-ms-filter: "progid:DXImageTransform.Microsoft.gradient(GradientType=0, startColorstr=#FF009900, endColorstr=#FF006600)";

And this is what it looks like in Internet Explorer 8:

While you site there flabbergasted that, once again, IE seems to have been ahead all along in the race to snazzy CSS3 effects, there are a couple of caveats. First off, like all IE filters, underlying this is an ActiveX control, so expect strange issues related to stacking, clicking and (possibly) problems due to the security settings of extremely paranoid Windows admins. Secondly, you can't specify anything other than a flat gradient, there is no equivalent to colour stops. Finally, unlike the 'true' CSS gradients in Firefox and Safari, a filter in IE applies to the entire element instead of just a single property. So while in Firefox you can happily use a gradient in the background-image property and also specify a separate box-shadow property, in IE you have to use all the filters on a single -ms-filter property; this may not be a problem for you, but I've found that combining more than one filter of a different type on a single element can lead to some rather strange results, more on this below.

In my final example in my earlier post, I tried to do some no Image Aqua Buttons without adding additional markup to my fake menu. You may recall one of the issues I had was simulating the 'glare' with a radial gradient because there wasn't a way to make it anything other than round. In the new gradient syntax supported by Firefox, there is now a way to change the shape of the radial gradient:

background-image: -moz-radial-gradient(center 25%, ellipse farthest-side, rgba(255, 255, 255, 0.7), rgba(255, 255, 255, 0.1) 50%, rgba(255, 255, 255, 0));

You can now specify a shape, circle or ellipse, as well as a number of different 'size constants' - farthest-side in my example above. This allows a lot more flexibility for the radial gradients. Compare the orginal version:

With the new 'ellipse farthest-side' version:

Yes, I know, the difference is subtle

As I alluded to above, the main issue with these buttons is that we want them to be semi-transparent. Apart from IE, it's been a while since any other major browser didn't support RGBA colour - Opera 9.64 didn't support it, but Firefox 3.0 did. As long as a non-transparent colour is an acceptable fallback we can just rely on normal CSS precedence and specify two background colours:

background-color: rgb(60, 132, 198);
background-color: rgba(60, 132, 198, 0.8);

If you want a completely transparent background in the case where gradients are supported and a coloured background otherwise, you can specify everything in two background rules instead, browsers should ignore the rules they don't understand.:

background: rgb(60, 132, 198);
background: -moz-linear-gradient(left, rgba(28, 91, 155, 0.8), rgba(108, 191, 255, 0.9)) transparent;

Once again for IE we turn to the -ms-filter property. In the earlier gradient example you will have seen startColorstr=#FF009900 - the alpha value is that first hexadecimal pair (the rest make up a standard hex colour decleration), if you set it to something less than FF the colour will be partly transparent. Since I have two elements to use, the li and the a within it, I will attach a gradient filter to both:

div#nav2 ul li {
    -ms-filter: "progid:DXImageTransform.Microsoft.gradient(GradientType=1, startColorstr=#CC1C5B9B, endColorstr=#E56CBFFF)";
}
div#nav2 ul li a {
    -ms-filter: "progid:DXImageTransform.Microsoft.gradient(GradientType=0, startColorstr=#88FFFFFF, endColorstr=#00FFFFFF)";
}

The GradientType is 1 for horizontal and 0 for vertical, so the first declaration is a relatively solid dark blue to light blue horizontal gradient and the second declaration is a white to transparent vertical gradient. Finally in IE, because the -ms-filter property is stand-alone, the normal background colour has to be turned off in conditional commennts:

<!--[if IE]>
<style type="text/css">
h1, div#nav1 ul li, div#nav2 ul li, div#nav2 ul li a {
    background-color: transparent;
}
</style>
<![endif]-->

This produces some acceptably 'glassy' buttons:

In Gecko and WebKit there is also text and box shadow, these can also be emulated by -ms-filter in IE8. It is possible to tack multiple filters on to the declaration like this:

div#nav2 ul li {
    -ms-filter: "progid:DXImageTransform.Microsoft.gradient(GradientType=1, startColorstr=#CC1C5B9B, endColorstr=#E56CBFFF) progid:DXImageTransform.Microsoft.Shadow(color=#3399EE,direction=180,strength=10)";
}
div#nav2 ul li a {
    -ms-filter: "progid:DXImageTransform.Microsoft.gradient(GradientType=0, startColorstr=#88FFFFFF, endColorstr=#00FFFFFF) progid:DXImageTransform.Microsoft.Shadow(color=#3399EE,direction=180,strength=10)";
}

The filters are applied in the order they appear in the rule. However, as I alluded to above, this doesn't always have the effect you might expect, here's the result of the above rules:

Not very useful! You may have better luck mixing other filters, or applying multiple filters of the same type, but in general I would recommend a one filter per element approach. In this case, I think the gradient is more important than the shadow for the general feel, so I'll stick with that.

So now the final 'compatible' version of my example page is ready. For some side by side comparisons, here it is at it's best in Firefox 3.6:

This is the same page in Internet Explorer 8:

And this is the same page again in the legacy Opera 9.64:

As you can see, the pages are by no means identical in every browser, but each is displaying the page according to its capabilities, with no need for Javascript hacks and only a little CSS trickery. So, if you are willing to accept that less capable browsers will show less stylish pages (and are willing to write a few redundant CSS rules), it is possible to use several CSS3 features on websites today.
